P10 Outdoor Full Color LED Display
P10 Outdoor Full Color LED Display is a general purpose information and advertisement displaying unit which is commonly used in outdoor areas in large shopping complexes, business firms and various commercial places such as airports, metro stations and many more. It has a high pixel density of 1000 dots per meter square with an adjustable brightness in between 5500 to 6000 candela per square meter. The offered display provides good protection against water, dirt and dust due to its IP rating of IP65.
Technical specification
Active Screen Dimensions: | 320 X 160 mm |
Working Voltage: | 5 V |
Resolution: | 32 X 16 Pixels |
Pixel Density (dot per sq. m): | 10000 |
Power Consumption: | 841 Watt Per Meter Square |
Color: | Full Colour |
Blue Wavelength: | 470 to 475 nm |
Module Maximum Power: | 31 W |
Viewing Angle Vertical: | 120 Degree |
Red Wavelength: | 620 to 625 nm |
Waterproof Grade: | IP65 |
Brightness (cd per sq. m): | 5500 to 6000 |
Led Package: | SMD 3535 |
Scan Mode: | 1/4Scan |
Weight (g): | 460 |
Viewing Distance: | 10,000 - 2,50,000 Per Meter Square |
Waterproof: | Yes |
Drive IC: | MBI 5020 |
Best View Distance: | 12.5 m |
Power Supply: | 110/220V |
Green Wavelength: | 520 to 525 nm |
Viewing Angle Horizontal: | 140 Degree |
